AUGUST 250Kw 335Hp Fully Enclosed Motor Drive
Product Description
Fully Enclosed Motor Drive 250Kw 335Hp Kompresor Indonesia
- Air Cooled
- Twin Screw Single Stage Air End – August- Brand
- 5 Year Rotor Warranty
- 45,000-50,000 Working Hours Engineered Lifetime
- Skf Explorer Bearings (Mainly)
- Energy Saving Micro Control System, Fully Automated Operation
- Easy Maintenance
- Low-Noise Operation, Closed Cabinet Structure, Noise Reducing Dumping Mats Made Of Fire-Retardant Materials
- Belt Drive
- Drawing For Reference Only
- Efficient, Safe And Reliable Fully Enclosed Motor Drive (Ip54, F Class / Ip55 Optional)
- Energy Saving Air End 5:6 Helix
- Networkable Link Between Compressors / Grouping With On-Line, Remote Monitoring And Dsc Network Functions
- High Precision Heavy Duty Intake Filter 1Μm, 99.9% Efficiency
- Optimized Oil Separation System Residual Oil Rate 1-3Mg/M3
- Low Speed Air End Operation
- Powerful Low Noise Exhaust Fan / On Top Exhaust
- Automatic Control Of Functions / Maintenance Indicator
- English Language Display, Easy Operation, Running Status At A Glance, Runningreal-Time Monitoring Data
- Pressure And Temperature Control And Protection
- Start Up Protection ( Current Spike Free)
- English Language Display / English Language Manual
| Model | SF250A | SF250B | SF250C | SF250D |
| Free air delivery(m3/min) | 43.5 | 37.0 | 31.5 | 41.5 |
| cfm | 1536 | 1307 | 1112 | 1466 |
| l/s | 725 | 617 | 525 | 692 |
| Discharge pressure(MPa) | 0.7 | 1.0 | 1.3 | 0.8 |
| bar | 7 | 10 | 13 | 8 |
| psig | 102 | 145 | 189 | 116 |
| Ambient temperature(℃) | -5~+40 | |||
| Cooling method | Air cooling | |||
| Air supply temperature (℃) | Less Than Ambient temperature +15℃ | |||
| Drive method | Direct Coupling Drive | |||
| Start method | Star delta start | |||
| Noise dB(A)±3 | 83 | |||
| Power (kW/HP) | 250/335 | |||
| Overall dimension (mm) | 3380×2200×2400 | |||
| Weight (kg) | 5800 | |||
| Air supply out (Inch) | 4" | |||
| IE3 Version Compliance: | |||||||||||||||
| Motor Power (kw) | 15 | 18.5 | 22 | 30 | 37 | 55 | 75 | 90 | 110 | 132 | 160 | 185 | 200 | 220 | 250 |
| Efficiency | 92.1 | 92.6 | 93 | 93.6 | 93.7 | 94.3 | 94.7 | 95.2 | 95.4 | 95.6 | 95.8 | 95.7 | 95.8 | 95.8 | 95.8 |
High efficiency, energy saving and noise reduction elements are standard aspects in development and
production. The main product line reaches the standard of national Class 2 high efficiency requirements.
Furthermore Heat recovery systems, Permanent Magnet motor technology and VSD Inverter applications
are available to provide an even higher efficiency of the compressors. We combine the advanced
German technologies with the latest research achievement and rely on the core technology we own,
to establish our leading position in the industry and provide advanced solution to compressed air system
for customers in and outside China.
